PH-2200W-4

Sold per piece.

The PowerHouse Class A/B amplifiers perform much better than any normal output stage on the market. This technology allows these amps to produce more power while putting less of a load on your vehicle’s electrical system. This means more power to your speakers, no thermal shut-down problems, and longer play times than the competition. Additionally, they deliver an amazing frequency response and distortion as low as 0.001%.

€0,00

€0,00

Specifications
Model Name: PH-2200W-4
EAN: 0168975910417

Class: "A/B"
Channels: 4
THD: >0.005%
Signal to Noise Ratio: >104dB
Max Power: 2000W
RMS Power 2-Ohm Stereo: 4 x 250W
RMS Power 4-Ohm Stereo: 4 x 125W
RMS Power 4-Ohm Bridged: 2 x 500W

Massive 4-gauge power ground terminals
Massive 8-gauge speaker connections
0-gauge power ground terminals for competition amps
High level inputs
Low level inputs
Low Level outputs
High-pass/Full-range/Low-pass operation
Built-in crossover
High-pass filter
Bass boost

PH-2200W-4 Manual (ENG)

PH-2200W-4 Product Release (ENG)

PH-2200W-4 Schematics (ENG)
